Documentation Style Guide#

Overview#

This document contains rules that are to be followed when creating or updating this documentation repository, as well as some related tips and syntax.

All documentation files (generally Markdown) must be located within /docs/source/ or a subfolder.
- Most documentation category folders are located exactly at this level of the file structure.
Static assets (essentially anything that is not a Markdown file) shall be placed in /docs/source/_static.
- All image files shall be placed in /docs/source/_static/images or subfolders.
- All other asset files (ex. PDF) shall be placed in /docs/source/_static/files for now.
All static assets shall be placed in a subfolder reflecting their reference location in the main file tree.
- For example, if the file foo.png is embedded within /docs/source/metadocs/bar.md, then foo.png shall be placed in /docs/source/_static/images/metadocs.
- If there are many related images only used in a single note within that category, it is strongly preferred to create a folder sharing the title of the note to place those images in.
  - In the same example, foo1.png … foo20.png embedded within bar.md would be placed in /docs/source/_static/images/metadocs/bar.

Do not use spaces in any folder or file name.
Do not use capital lettering for any folder or file name without explicit approval from the project manager.
- The reason for this is that links in the final product (on ReadTheDocs.io) are case-sensitive. Maintaining a consistent format helps reduce errors.
Documentation category folder names (i.e., folders under /docs/source/) shall use lower kebab case (ex. data-aq).
File names for Markdown files and assets (i.e., images) shall use lower kebab case (ex. documentation-style-guide.md).

Each Markdown file shall have only one H1 tag (#).
Do not add spaces between consecutive headers, or between headers and their following text.
Organize Markdown files intelligently.
- For example, if you write a brief overview of what the file is at the top, create an H2 (##) titled Overview. Then put the rest of the content under other headers, such as Instructions and Examples.
Text should generally be bulleted and short.
- Do not write long-form prose. Break it up into manageable chunks with bulleted or numbered lists.
Any reference to a version number such as “V3” shall be formatted with an uppercase V.
- For instance, Quarterback V3 is formatted as such, not as Quarterback v3.
As cursed as it is, “quarterback” is one word, and “running back” is two words. Use this and be consistent.

Line comments may be added using %. These will appear in the source Markdown file, but will not appear in the automatically generated HTML (and by extension the webpage).

In order to link from one Markdown file to another, use the format below.
- For instance, linking to the Sphinx page in this directory would take the form [Sphinx](./sphinx), where the . denotes the current directory.
- However, linking to a file in another directory, such as Bot Types, would look like this: [Bot Types](../high-level/bot-types), where .. denotes the parent of the current directory.

[Link Display Name](relative path with space escapes)

In order to link to a heading in the same file, use the format below.
- Linking to the heading in another file essentially follows the same rules as above.
- ReadTheDocs provides heading links for each note with forced lowercase and spaces formatted as dashes. For instance, linking to this header would look like this: [this header](#linking-and-embedding)

[Link Display Name](#lower-kebab-case-heading-name)

To embed an image, prefix a link to the image with an exclamation point (!).
- Some other URLs or assets can also be embedded this way, if Sphinx/ReadTheDocs supports them.
- For example, including /docs/source/_static/images/klondike-facepalm.png from this file would look like this: ![Image Alt Text](../_static/images/klondike-facepalm.png)
- To change the size or alignment of an image, use attrs_inline syntax.
  - For example, to center align an image and set the width to 100 pixels: ![Image Alt Text](../_static/images/klondike-facepalm.png){w=100px align=center}
  - See also: https://myst-parser.readthedocs.io/en/latest/syntax/images_and_figures.html
Although it may be convenient to edit the documentation repository in Obsidian, regular Obsidian double-bracket links do not work.
- However, this type of HTML file link does work in Obsidian.
  - Header links with spaces do not work since RTD formats spaces as dashes.
    - Since Obsidian links are case-insensitive, that part of the formatting is irrelevant.
